| Flatdeck 3/4 ton 14 inch (unbraked)
-
Trailers
-
Commercial Trailers
|
 | Back left view
|
|  | front left view
|
|  | Back left view open
|
|  | 14 inch wheel
|
|  | Spare wheel holder
|
|  | Back left view of tailgate
|
|  | Rear tailgate pivot
|
|  | Support leg up
|
|  | Support leg down
|
|
|
|
|
Flatdeck 3/4 ton 14 inch (unbraked)
1. Superb for transportion of bulky heavy weight goods.
2. A well balanced, multi purpose, heavy duty trailer. Durable, yet light for towing.
3. Body constructed from 1.6mm corrosion resistant electro galvanized sheet steel.
4. Floor constructed from 1.6 mm corrosion resistant electro galvanized sheet steel.
6. Superb for transportion of bulky heavy weight goods.
7. Tailgate folds down to facilitate loading.
8. Including spare wheel 195x14 inch
|
|
| Dimensions | | A | Height (over all) | 1390 mm |
|---|
| B | Height (side) | 870 mm |
|---|
| C | Length (body) | 2360 mm |
|---|
| D | Length (over all) | 3280 mm |
|---|
| E | Width (inside) | 1400 mm |
|---|
| F | Width (over all) | 1855 mm |
|---|
| G | Ground Clearance | 245 mm |
|---|
| Technical Info | | Tare Mass | 280 kg | | GVM | 750 kg | | Pay Load | 470 kg | | Brakes | No brakes | | Axle Length | 1700 mm | | Axle Capacity | 1250 kg | | Leaf Springs | 8 Blade 36 inch | | Wheels | 195 x 14 inch 6 stud |
|
|
| Subject to our general terms and conditions of supply and delivery.
Technical data, pricing, dimensions, and weights are subject to change, due to
a policy of continual product development. The illustrations are for reference
only. Dimensions are in millimetres. Venter Trailers reserves the right to
alter design and specifications without prior notice. |
